Best Lab Allihn Condensers in 2026

HIGH EFFICIENCY In a soxhlet extraction,the sample material contained in the soxhlet thimble can be extracted multiple time automatically with a small solvent dosage in high efficiency.Comparing to the steam ,solvent extraction happpens at a lower temperature which will dissociation of the compounds in the extracts from plants sensitive to temperature.

DIMENSIONS---The glass Soxhlet extractor set with 55/50 upper and 24/40 lower joint including an allihn reflux condenser with a water cooled inner drip joint at bottom ,the jacket length is 300mm,Overall height is 405mm,the joint is 55/50; A soxhlet extractor tube, with 55/50 upper joint and 24/40 lower joint.;An all- glass soxhlet thimble with sealed in fritted disc for which the pore diameter is from is from 20 to 35 μm.

WIDELY USED :Soxhlet extraction, also known as fat extraction,continuous extraction , is a laboratory apparatus for extracting compounds from solid material. Soxhlet extractors are often used for the determination of crude fat content.,Which is determined by extracting the fat from the sample using a solvent.It also can be used to extract essential oils from plant material by food grade solvents

Used for laboratory-scale refluxing, botanical extraction or continuous extraction of solids with a suitable solvent and etc.

Consist of 1 Soxhlet extractor with standard 50/42 joint, 1 Allihn condenser, and 2 24/29 500 ml flat bottom flasks

Made of Borosilicate glass

Used for laboratory scale refluxing, botanical extraction or continuous extraction of solids with a suitable solvent and etc

Consist of 1 Soxhlet extractor with standard 45/40 joint, 1 Allihn condenser, and 2 24/40 500 ml flat bottom flasks

Made of borosilicate glass

Sturdy and trustworthy tool that can help you to complete your experiments.

This condenser pipe is perfect for home education, chemistry lesson and laboratory use.

It can improve kids imagination and hands-on ability through interactive play.

COMPONENT----This kit includes most commonly used lab jointed glassware with 24/40 joint and other accessories like penny head stopper,cork stand,bosshead clamp,3finger double adjustabe clamp,plastic andalloy joint clips.The glassware includes thermometer adapter,vacuum adapter,claisen adapter,3 way thermometer adapter,3 way adapter,liebig condenser,allihn condenser,fractinal column,graham condenser,separatory funnel, buchner funnel.

USE----This kit can be used to assemble a simple apparatus,a water and steam apparatus, a fractionation apparatus,a reflux setup.Allihn,graham condenser are usually used as a reflux condenser,while liebig condenser can be used both in a apparatus but also a reflux setup.The separatory funnel with two joints can be also be used as an addtion funnel.

DIMENSIONS------All the glass condensers in this kit are 300mm in effective length.The single neck, 2 neck ,3 neck flask with capacity from 250mL to 1000mL,the separatory funnel is with capacity of 250mL,all the joints in this kit are 24/40.

Be Made From G3.3 Borosilicate Glass

Annealing Point ------610℃

Linear Coefficient of Expansion------ 32×10-57/℃

This is a special allihn condenser only with 34/45 bottom male joint inserting to a soxhlet extractor body ,the size is larger with an inner tube consisting of a series of bulbs which increase the surface area availiable for vapor condensation surrounded by an outer jacket tube.This design can improve the cooling performance,in practise, the allihn condenser can be replaced by a liebig condenser, coiled condenser,dirmoth condenser or graham condenser used as a reflux condenser.

In a soxhlet extraction apparatus, this allihn condenser with lower male joint attached the soxhlet extractor body cools the solvent vapour from the boiling flask and drips back down into the thimble containing the solid material. With 10mm O.D.hose connections at top and bottom accommodating 8mm I.D.rubber tubing,the cool water flows in from the lower hose ,and flows out from the upper hose.

The glass allihn condenser is with 55/50 male joint, 300mm in jacket length 405mn overall height

This condenser pipe is perfect for home education, chemistry lesson and laboratory use.

Sturdy and trustworthy tool that can help you to complete your experiments.

It can improve kids imagination and hands-on ability through interactive play.

This is a special allihn condenser only with 34/45 bottom male joint inserting to a soxhlet extractor body,the size is larger with an inner tube consisting of a series of bulbs which increase the surface area available for vapor condensation surrounded by an outer jacket tube.This design can improve the cooling performance,in practise, the allihn condenser can be replaced by a liebig condenser, coiled condenser,dirmoth condenser or graham condenser used as a reflux condenser.

In a soxhlet extraction apparatus, this allihn condenser with lower male joint attached the soxhlet extractor body cools the solvent vapour from the boiling flask and drips back down into the thimble containing the solid material. With 10mm O.D.hose connections at top and bottom accommodating 8mm I.D.rubber tubing,the cool water flows in from the lower hose ,and flows out from the upper hose.

The glass allihn condenser is with 45/50 male joint, 260mm in jacket length 365mn overall height

Be Made From G3.3 Borosilicate Glass

Annealing Point ------560℃

Linear Coefficient of Expansion------ 32×10-7/℃
